Energy Storage / Perihelion / Residential

Perihelion Aura

A streamlined wall-mounted or floor-standing battery for residential energy storage.

Discuss this product
Perihelion Aura residential battery
Perihelion · Residential

Product overview

A streamlined wall-mounted or floor-standing battery for residential energy storage.

Back to Residential energy storage
At a glance
  1. 10.24 / 15.36 kWh configurations
  2. 51.2 V low-voltage battery
  3. Wall or floor; IP20 / IP54 option
Product architecture

Applications

Architecture

The design keeps the battery enclosure simple and placement flexible. Power conversion, backup switching and system control are coordinated around it as project-level choices.

Inside Perihelion Aura

  • Residential battery enclosure
  • Wall or floor installation form
  • Compact local display

Confirm around the product

  • Compatible inverter or PCS
  • Backup and load-side architecture
  • Site protection, metering and controls
Configurations
Configuration 01

10.24 kWh wall-mounted

  • 10.24 kWh
  • 51.2 V DC
  • 100 A
  • IP20 / IP54 option
Configuration 02

15.36 kWh floor-standing

  • 15.36 kWh
  • 51.2 V DC
  • 200 A
  • Floor-standing
Applications

Space-conscious home storage

Consider Aura where the battery position needs to adapt to an existing utility or energy room.

Residential solar planning

Use Aura as the battery layer in a wider solar-and-storage design after inverter compatibility is confirmed.

Backup-ready system design

Coordinate the battery with the project-specific switching, controls and protected-load plan.

Technical information

Technical data by configuration

Compare specifications by configuration. Controls, protection and local requirements are addressed during system design.

Perihelion Aura

10.24 kWh wall-mounted

A compact 51.2 V residential battery for wall installation, with an IP54 enclosure available where the project requires it.

01 · Battery and electrical
ParameterValue
Rated energy10.24 kWh
Nominal voltage51.2 V DC
Operating voltage range43.2–57.6 V DC
Nominal capacity200 Ah
Max. charge / discharge current100 A
Depth of discharge90%
Cycle life≥6,000 cycles at 25°C, 80% DOD
01 · Installation and environment
ParameterValue
InstallationWall-mounted
Ingress protectionIP20; IP54 option
Product dimensions555 × 820 × 200 mm
Net weight96 kg
Working temperature0–55°C
Storage temperature−20–55°C
Relative humidity≤80%
Perihelion Aura

15.36 kWh floor-standing

A higher-capacity 51.2 V floor-standing battery with a touchscreen and LED status interface.

02 · Battery and electrical
ParameterValue
Rated energy15.36 kWh
Nominal voltage51.2 V DC
Operating voltage range43.2–57.6 V DC
Nominal capacity300 Ah
Max. charge / discharge current200 A
Depth of discharge90%
Cycle life≥6,000 cycles at 25°C, 80% DOD
02 · Installation and environment
ParameterValue
InstallationFloor-standing
Ingress protectionIP20
Product dimensions850 × 530 × 250 mm
Net weight130 kg
Local interfaceTouchscreen and LED status light
Working temperature0–55°C
Storage temperature−20–55°C

Prepare a useful enquiry

Bring these four project inputs to the first sizing conversation:

  • Target usable energy
  • Grid phase and voltage
  • Backup-load scope
  • Mounting environment

Certifications and compliance

  • CE
  • UL
  • FCC
  • UN 38.3
  • MSDS

Certification marks apply to the published product family; final market applicability follows the selected configuration.
