Energy Storage / Perihelion / Residential

Perihelion Halo

An all-in-one residential system bringing the battery, inverter, BMS and energy control into one integrated design.

Discuss this product
Perihelion Halo residential all-in-one
Perihelion · Residential

Product overview

An all-in-one residential system bringing the battery, inverter, BMS and energy control into one integrated design.

Back to Residential energy storage
At a glance
  1. 3 / 5 kW integrated power
  2. 2.56 / 10.24 kWh storage
  3. Wall, floor or modular stack
Product architecture

Applications

Architecture

Its role in the Perihelion range is consolidation. The integrated enclosure establishes a clear equipment boundary while the final grid, solar and backup connections remain part of project design.

Inside Perihelion Halo

  • Battery and inverter
  • Battery management system
  • Energy control and local display

Confirm around the product

  • PV and grid connection design
  • Backup loads and switching scope
  • Site metering and communications
Configurations
Configuration 01

5 kW / 10.24 kWh modular all-in-one

  • 5 kW
  • 10.24 kWh
  • 51.2 V battery
  • Two battery modules
Configuration 02

3 kW / 2.56 kWh compact all-in-one

  • 3 kW
  • 2.56 kWh
  • 25.6 V battery
  • Wall or floor
Applications

Consolidated home upgrade

Consider Halo when a project calls for a single coordinated residential storage enclosure.

Solar and storage integration

Plan the product as the central equipment layer between the home, solar generation and the grid.

New-build energy rooms

Use the integrated boundary to organise electrical, metering and protected-load decisions early in design.

Technical information

Technical data by configuration

Compare specifications by configuration. Controls, protection and local requirements are addressed during system design.

Perihelion Halo

5 kW / 10.24 kWh modular all-in-one

A two-module residential stack combining a 5 kW inverter with 10.24 kWh of low-voltage battery storage.

01 · Battery and power conversion
ParameterValue
Rated AC output power5,000 W
Total battery energy10.24 kWh
Battery arrangement2 × 5.12 kWh modules
Nominal battery voltage51.2 V DC
Battery voltage range43.2–57.6 V DC
Rated AC voltage230 V AC
Rated frequency50 / 60 Hz
01 · PV input and enclosure
ParameterValue
PV input power5,500 W
PV operating voltage range120–450 V DC
Max. PV input voltage500 V DC
Ingress protectionIP20
System dimensions550 × 500 × 631 mm
Working temperature0–55°C
Storage temperature−20–55°C
Perihelion Halo

3 kW / 2.56 kWh compact all-in-one

A compact all-in-one unit for wall or floor installation with a 3 kW output and built-in fan cooling.

02 · Battery and power conversion
ParameterValue
Rated AC output power3,000 W
Rated battery energy2.56 kWh
Nominal battery voltage25.6 V DC
Battery voltage range21.6–28.8 V DC
Max. charge / discharge current50 A
AC input / output voltage220–240 V AC
Rated frequency50 / 60 Hz
02 · PV input and enclosure
ParameterValue
PV input power1,600 W
MPPT voltage range30–128 V DC
Max. PV open-circuit voltage160 V DC
InstallationWall-mounted or floor-standing
CoolingBuilt-in fan
Ingress protectionIP20
Product dimensions410 × 845 × 195 mm
Net weight45 kg

Prepare a useful enquiry

Bring these four project inputs to the first sizing conversation:

  • Target usable energy
  • Grid phase and voltage
  • Backup-load scope
  • Mounting environment

Certifications and compliance

  • CE
  • UL
  • FCC
  • UN 38.3
  • MSDS

Certification marks apply to the published product family; final market applicability follows the selected configuration.

Perihelion series

Choose by system boundary

Compare products in this series by format, configuration and project requirements.

Aura

Perihelion Aura

A streamlined wall-mounted or floor-standing battery for residential energy storage.

View Perihelion Aura
Current product

Perihelion Halo

An all-in-one residential system bringing the battery, inverter, BMS and energy control into one integrated design.

Viewing now

Ascent

Perihelion Ascent

A modular high-voltage battery stack designed to expand with residential storage requirements.

View Perihelion Ascent
Core

Focal Core LV

51.2 V / 10.24 kWh low-voltage rack. A serviceable low-voltage rack pack that can be installed in a cabinet or mounted on a wall.

View Focal Core LV

Turn architecture into a project plan

Share the site phase, solar arrangement and backup scope so the current verified Halo project pack can be matched to the home.
